MGE Divers SMB Ratchet Reel is a development of the popular MGE standard Divers SMB reel, a great general purpose reel, ideal for use with SMB’s for drift diving as well as deploying a delayed SMB on a wreck dive! The MGE reel can also be used for some basic line laying on wrecks. The ratchet version allows reeling against a ratchet making locking off the reel easier. Made from a durable robust plastic the MGE reel is without doubt the most rugged reel we have used in our Centre!
The MGE Ratchet Reel has a clever but simple rotating control mechanism which allows a left or right handed user to easily switch between the 4 multi-function modes:
€¢ Clockwise ratchet.
€¢ Anti-clockwise ratchet.
€¢ Free flow mode is used for deploying SMBs.
€¢ Full-lock mode to provide tension for safety or decompression stops.
What€™s more, the centrally located control mechanism is designed for use with either hand, making this model more versatile than thumb trigger designs.
MGE SMB Ratchet Reel – Features
- Clockwise ratchet and Anti clockwise ratchet
- Free flow mode used for deploying Delayed SMBs
- Full-lock mode to provide tension for safety or decompression stops
- Suitable for left or right handed use without the need for modification.
- Suitable for all types of diving with 50 metre line and SMB clip.
- 50m of 2mm Polyester line with 90kg breaking strain
- MGE Reels are self lubricating
- The MGE Ratchet reel is fully serviceable and is lightweight and compact.
- The MGE Ratchet Reel is made fom rugged impact resistant polymers for extra durability.
MGE SMB Ratchet Reel Dimensions
- Overall Length – 19cm
- Width at handle (widest part) – 15cm
- Spool Diameter – 11cm (50m of 2mm line)
- Depth inc spool “Knob” – 10cm
- Spool “Knob” – 3cm
- 2 holes in handle will take 4-6mm bungee (available seperately)
- N.B All sizes are approximate
